If your S2 robot is unable to cross a threshold between rooms or struggles with small height transitions, follow the steps below to troubleshoot the issue and understand the robot’s design limitations.

Step 1: Clean and Maintain the Omni-Directional Wheel

• Dirt or debris on the omni wheel can reduce traction, making it difficult for the robot to cross thresholds.

• Regular cleaning ensures smooth operation. Please refer to the maintenance tutorial [Video: https://youtu.be/aTNrP6QlqF8].

Step 2: Remove Oil or Grease from Wheels

• Wheels contaminated with oil or slippery residue can lose grip.

• Wipe the wheels thoroughly with a dry cloth to restore traction.

Note: Do not drip water directly onto the robot, as moisture can damage internal components.

Step 3: Understand the Robot’s Threshold Limit

• When climbing a threshold, the robot’s front slightly lifts, triggering anti-drop sensors.

• For safety, the S2 robot can reliably cross thresholds up to 35 mm.

• Any threshold higher than 35 mm exceeds the robot’s design limit and may not be crossed successfully.

Step 4: Address Slippery Floors or Water Near Thresholds

• Wet or slippery surfaces near thresholds can cause the wheels to slip, preventing the robot from climbing.

• For higher or challenging thresholds, consider installing a small auxiliary ramp or threshold strip to help the robot transition smoothly.

Following these steps will improve threshold-crossing performance and help you understand the S2 robot’s design limitations.

If you have any additional questions or need further assistance with your S2 robot, please do not hesitate to contact our support team.
